Product specifications for the Mobi Portable Room Divider Range
Frame & panel measurements
Frame thickness - 11mm
Frame width (Top Bar) - 15mm /(Bottom Bar) - 47mm
Panel size - 687mm
Stability feet - 500 x 50 x 4mm
From bottom of panel to floor - 50mm
Materials
Frame - Powder coated aluminium
Castor wheels - Polypropylene
Stability Feet - Steel
*Stability feet are trip and wheelchair friendly with round edges
Fire Safety Elements
Laminate
Tested to standard UNE EN 13501-1:07+A1:2010
Anti-bacterial
Garbe fabric collection has been tested and passed BS 5852 Crib 5 - EN1021 1+2
Flammability performance is dependent upon components used
Loop Nylon
Loop Nylon fabric has been tested to BS 5867-2 : Type B : 2008
Flammability performance is dependent upon components used
Plastic Components
Manufactured using non-flammable, self-extinguishing plastic.
Aluminium
Has a melting of 660°C and is not considered to be a fire hazard.
Panel Finish Information
Easy Clean: HPL (high pressure laminate)
Anti-Bacterial: Garbe Fabric 88% PVC / 12% Poly/Cotton
Fabric: Brushed loop nylon
Printed: Gloss varnish finish
Product Weights for Mobi Loop Nylon
Box Size
Please note: box sizes & quantities vary based on order volume and panel size.
1200mm High = 130 x 75 x 10cm
1500mm High = 160 x 75 x 10cm
1800mm high = 190 x 75 x 10cm
Weights
Weight includes all framework, stability feet & packaging
1200mm High
2 way - 6.3kg
3 way - 8.3kg
4 way - 17.2kg
5 way - 14.3kg
6 way - 16.6kg
7 way - 18.1kg
8 way - 19.6kg
9 way - 22.1kg
1500mm High
2 way - 7.25kg
3 way - 10.1kg
4 way - 15.4kg
5 way - 17.3kg
6 way - 21kg
7 way - 21.6kg
8 way - 23.6kg
9 way - 26.6kg
1800mm High
2 way - 9.8kg
3 way - 14.3kg
4 way - 17.3kg
5 way - 18.5kg
6 way - 21.5kg
7 way - 25kg
8 way - 32kg
9 way - 35.6kg
